Description
The InfiRay Outdoor RICO HYBRID fuses the capabilities of a thermal clip-on and a thermal weapon sight to create a new breed of thermal device. The HYBRID gives you never-before-seen versatility and performance, boasting a 3,600 yard detection range as a dedicated thermal sight, or compatibility with day optics up to 10× as an inline clip-on sight. The combination of the HYBRID’s low-distortion orthoscopic eyepiece and a 1.03-inch large-format 2560×1920 display provides comfortable viewing as a dedicated sight while still maintaining the pixel density and resolution for use as a clip-on optic. The HYBRID also unlocks advanced features such as compatibility with a 1,000 yard laser rangefinder, a custom reticle generator, Bluetooth remote, and an onboard ballistic solver.
The ILR-1000-2 Laser Rangefinder (AC82) connects to the HYBRID via USB-C (data and power), providing real-time ranging data that can even integrate with user-supplied ballistics data and apply hold-over on a custom reticle. See page 45 for details.
PLEASE NOTE: The HYH50W and HYH75W both use a IBP-1 type battery (4400mAh). THE IBP-1 battery that ships with the HYH50W is the same battery used by the RICO Mk1 and RICO Pro Series. The battery that ships with the HYH75W is an enhanced IBP-1 that features the FDE ceramic coated finish and improved ingress protection. The HYH75W will run on the original IBP-1 battery, but will not be IP67 weatherproof in this configuration. For best results, always use the batteries that shipped with the product.
-
Optics
Objective Focal Length
75mm
Detection Range
3600 Yards
Optical Magnification
4X
Digital Magnification
8X
Objective Lens Material
Germanium
Horizontal Angular Field of View
5.9°
Vertical Angular Field of View
4.4°
Objective Diameter
75mm
Objective F#
1.0
Focusing Mechanism
Manual Focus
Eye Relief
60mm
Diopter Range
-4 to +2
Display Type
AMOLED
Display Resolution
2560×1920
-
Features & Performance
Power Source
USB-C External, IBP-1H Li-ion Battery Pack
Reticle
9 (7 Static, 1 DIY, 1 BDC)
Color Palettes
White Hot, Black Hot, Red Hot, Iron Red, Rainbow, Outline
Rangefinder
ILR-1000-2 LRF (Optional/Not Included)
Stand-by Mode
Yes
One-Shot Zero
Yes
Picture-in-Picture
Yes
Wifi
Yes
Image Capture
Yes
Mobile App
Yes
User-Updatable Firmware
Yes
Connector Type
USB-C
Connector Output
Power/Data
Onboard Recording
Yes
Storage Capacity
64GB
Run Time
6+
External Power Source
USB-C
Warranty
5 Years
Startup Time
<10 Seconds, Instant from Standby
Country of Manufacture
China
-
Environmental Specifications
Operating Temperature Range
-4°F~122°F
Ingress Protection
IP67
Recoil Rating
1000 g/s² (300 Win./7mm Mag)
-
Physical
Weight
45.08 Oz.
Height
3.58
Width
4.13
Length
12.20
Housing Material
Magnesium Alloy
Mounting Interface
Picatinny MIL-STD 1913 Rail
-
Sensor Specifications
Device Technology
Thermal Imaging
Sensor Type
InfiRay MICRO II
Sensor Resolution
640×512
Sensor Pixel Size
12?m
Sensor Frame Rate
50hz
Thermal Sensitivity
<25mk
Non-Uniformity Correction (NUC)
Manual, Automatic, Semi-Automatic
-
Optics
Objective Focal Length
75mm
Detection Range
3600 Yards
Optical Magnification
4X
Digital Magnification
8X
Objective Lens Material
Germanium
Horizontal Angular Field of View
5.9°
Vertical Angular Field of View
4.4°
Objective Diameter
75mm
Objective F#
1.0
Focusing Mechanism
Manual Focus
Eye Relief
60mm
Diopter Range
-4 to +2
Display Type
AMOLED
Display Resolution
2560×1920
-
Features & Performance
Power Source
USB-C External, IBP-1H Li-ion Battery Pack
Reticle
9 (7 Static, 1 DIY, 1 BDC)
Color Palettes
White Hot, Black Hot, Red Hot, Iron Red, Rainbow, Outline
Rangefinder
ILR-1000-2 LRF (Optional/Not Included)
Stand-by Mode
Yes
One-Shot Zero
Yes
Picture-in-Picture
Yes
Wifi
Yes
Image Capture
Yes
Mobile App
Yes
User-Updatable Firmware
Yes
Connector Type
USB-C
Connector Output
Power/Data
Onboard Recording
Yes
Storage Capacity
64GB
Run Time
6+
External Power Source
USB-C
Warranty
5 Years
Startup Time
<10 Seconds, Instant from Standby
Country of Manufacture
China
-
Environmental Specifications
Operating Temperature Range
-4°F~122°F
Ingress Protection
IP67
Recoil Rating
1000 g/s² (300 Win./7mm Mag)
-
Physical
Weight
45.08 Oz.
Height
3.58
Width
4.13
Length
12.20
Housing Material
Magnesium Alloy
Mounting Interface
Picatinny MIL-STD 1913 Rail
-
Sensor Specifications
Device Technology
Thermal Imaging
Sensor Type
InfiRay MICRO II
Sensor Resolution
640×512
Sensor Pixel Size
12?m
Sensor Frame Rate
50hz
Thermal Sensitivity
<25mk
Non-Uniformity Correction (NUC)
Manual, Automatic, Semi-Automatic
