Garmin GPSMAP® 8612xsv

$4,099.99

Available on backorder

Garmin U.S. East Inland Maps microSD™/SD™ card: LVUS106F-LakeVü g3 Ultra East

Garmin U.S., West Inland Maps LakeVü g3 Ultra | LVUS107F | microSD™/SD™

Garmin U.S. Inland Maps LakeVü g3 | LUS100F | microSD™/SD™

SKU: 010-02092-51 Category: Tags: , , Brand:

Description

  • GPSMAP 8612xsv
  • Power cable
  • NMEA 2000® drop cable
  • NMEA 2000 T-connector
  • Bail mount with knobs
  • Flush mount kit
  • Sun cover
  • Trim piece snap covers
  • Documentation

Physical & Performance

Display Size 10.1″ x 5.7″; 11.6″ diagonal, 25.7 cm x 14.5 cm; 29.5 cm diagonal
Power Input 10 to 32 Vdc
Display resolution 1920 x 1080 pixels
GPS Yes
Dimension 11.9″ x 8.5″ x 3″ (30.3 cm x 21.6 cm x 7.6 cm)
Receiver 10 Hz
Waterproof IPX7
Weight 6.0 lbs (2.7 kg)
Mounting Options Bail, flat or flush (Garmin does not offer any hardware or accessories for a flat-mount installation. Professional tools and knowledge is required.)
Display Type FHD, IPS

Maps & Navigation

Garmin Navionics Vision+™ Yes
Accepts Data Cards 2 microSD cards
Garmin Navionics+ Inland & Coastal Yes
Navigation Routes 100
Garmin Navionics+™ Yes

Features

Waypoints 5000
Sailing Features Yes
NMEA 0183 Compatible Yes
Has built-in receiver Yes
USB ports Yes
TOPO Yes
SideVü built-in 260/455/800/1000/1200 kHz
DSC Yes
Touchscreen Yes
LakeVü g3 Ultra No
NMEA 2000 Compatible Yes
ActiveCaptain® compatible yes
Typical current draw at 12 Vdc 1.3 A
NMEA 2000® ports 1
Tide tables Yes
GLONASS Yes
Track points 50,000
Panoptix™ sonar Yes
Garmin Marine Network Ports 2
LakeVü g3 No
Supports WAAS Yes
GSD Black Box Sonar Support Yes
Maximum current draw at 12 Vdc 6.0 A
Smart Mode Compatible Yes
Built-in Auto Guidance No
Maximum power usage at 10 Vdc 45W
BlueChart g3 No
Standard Mapping Yes
LakeVu (inland) No
Built-in Auto Guidance+ Yes
Displays sonar Yes
ANT+ (Connectivity) Yes
GCV Black Box Sonar Support Yes
BNC external GPS antenna port No
Connections NMEA0183 Input Ports 1
Spoken audio alerts Yes
BlueChart g3 Vision No
Garmin Wi-Fi network (local connection) Yes
J1939 ports 1
Input Touchscreen
Garmin Quickdraw Contours Yes
BLUETOOTH® pairing Yes
AIS Yes
Video output ports 1 HDMI
Raster chart support Yes
NMEA 0183 input (Tx) ports 1
OneHelm support Yes
ClearVü built-in 260/455/800/1000/1200 kHz
Tracks 50 saved tracks
Wireless Remote Compatible Yes
Supports Fusion-Link™ compatible radios Yes
Galileo Yes
LiveScope Yes
Power output 1 kW
BlueChart (coastal) No
Traditional sonar (dual frequency/beam) built-in (dual channel CHIRP, 70/83/200 kHz, L, M, H CHIRP)
GRID (Garmin Remote Input Device) compatible Yes
Video input ports 1 (BNC composite); 1 HDMI (HDCP compliant)

Additional information

Weight 15.1 lbs
Dimensions 16.929 × 12.008 × 9.005 in
