Garmin ECHOMAP™ UHD2 93sv without Transducer; Includes Garmin Navionics+ U.S. Inland Mapping

$1,099.99

Available on backorder

Garmin U.S. East Inland Maps microSD™/SD™ card: LVUS106F-LakeVü g3 Ultra East

Garmin U.S., West Inland Maps LakeVü g3 Ultra | LVUS107F | microSD™/SD™

Garmin U.S. Inland Maps LakeVü g3 | LUS100F | microSD™/SD™

SKU: 010-02688-00 Category: Tags: , , , Brand:

Description

  • ECHOMAP UHD2 (device will vary depending on selection)
  • 12-pin sounder to 8-pin transducer cable
  • Power cable
  • Tilt mount with quick-release cradle
  • Protective cover
  • Hardware
  • Documentation

Physical & Performance

Display Size 7.8″ x 4.5″, 9.0″ (19.8 x 11.5 cm, 22.9 cm)
Power Input 9 to 18 Vdc
Display resolution 1024 x 600 pixels
GPS Yes
Dimension 10.4″ x 6.5″ x 3.2″ (26.4 x 16.6 x 8.0 cm)
Receiver 10 Hz
Waterproof IPX7
Weight 2.9 lbs (1.3 kg)
Mounting Options Bail or flush
Display Type WSVGA, TN

Maps & Navigation

Garmin Navionics+ (Coastal) yes (see Additional)
Garmin Navionics Vision+™ Yes
Accepts Data Cards 1 microSD™ card; 32 GB maximum size
Garmin Navionics+ Inland & Coastal yes (see Additional)
Garmin Navionics+ (Inland) yes (see Additional)
Navigation Routes 100
Garmin Navionics+™ Yes

Features

Waypoints 5,000
Sailing Features Yes
NMEA 0183 Compatible No
Has built-in receiver Yes
USB ports No
TOPO Yes
SideVü built-in 260/455/800/1000/1200 kHz
DSC Yes
Touchscreen Yes
Additional
  • Garmin Navionics+ (inland and coastal): 95sv Canada, Australia and New Zealand
  • Garmin Navionics+ (coastal): 94sv U.S. coastal, 95sv UK/Ireland
  • Garmin Navionics+ (inland): 93sv U.S. lakes
  • Tide tables: 93sv, 94sv, 95sv
LakeVü g3 Ultra No
NMEA 2000 Compatible Yes
ActiveCaptain® compatible yes
Typical current draw at 12 Vdc 1.72 A
NMEA 2000® ports yes
Tide tables yes (see Additional)
GLONASS Yes
Track points 50,000
Panoptix™ sonar Yes
Garmin Marine Network Ports 1
LakeVü g3 No
Supports WAAS Yes
GSD Black Box Sonar Support No
Maximum current draw at 12 Vdc 3.5 A
Smart Mode Compatible No
Built-in Auto Guidance No
Maximum power usage at 10 Vdc 20.7W
BlueChart g3 No
Standard Mapping Yes
LakeVu (inland) No
Built-in Auto Guidance+ yes (downloadable via ActiveCaptain app)
Displays sonar Yes
ANT+ (Connectivity) Yes
GCV Black Box Sonar Support No
BNC external GPS antenna port No
Spoken audio alerts No
BlueChart g3 Vision No
Garmin Wi-Fi network (local connection) Yes
Input Touchscreen with Keyed Assist
BeiDou Yes
Garmin Quickdraw Contours Yes
BLUETOOTH® pairing Yes
AIS Yes
Supports multi-band, multi-constellation GPS Yes
Raster chart support No
OneHelm support No
ClearVü built-in 260/455/800/1000/1200 kHz
Tracks 50 saved tracks
Wireless Remote Compatible No
Supports Fusion-Link™ compatible radios Yes
Galileo Yes
LiveScope Yes
Power output 500 W
12-pin transducer ports 1
BlueChart (coastal) No
Traditional sonar (dual frequency/beam) built-in (single channel CHIRP, 50/77/83/200 kHz, L, M, H CHIRP)
GRID (Garmin Remote Input Device) compatible No

Additional information

Weight 5.67 lbs
Dimensions 13.346 × 10.118 × 7.874 in
